Hammer Iron Ve
The Hammer Iron Ve is a rugged smartphone designed for folks who work in demanding environments like construction sites or in harsh outdoors. The device features a 6.52-inch IPS touchscreen with a resolution of 720 x 1600 pixels and a 20:9 aspect ratio.
The device runs on Google Android 13 out of the box, and it is powered by the Mediatek Helio G36 chipset, which includes an octa-core CPU and a PowerVR GE8320 GPU. The phone comes with 6GB of RAM and 64GB of internal storage, expandable up to 512GB via a dedicated SD card slot.
The camera system features a 50MP main camera and a 24MP night vision camera with dual infrared night vision lights. For selfies, there is an 8MP fixed-focus front camera. Both the main and front cameras support 1080p video recording at 30fps, with the main camera also featuring an LED flash.
As stated before, the Iron Ve is built to withstand harsh environments, with IP68, IP69K, and Mil-STD-810H ratings for water, dust, and drop resistance up to 1.5 meters. The phone’s dimensions are 173 x 83 x 13.6 mm, and it weighs exactly 301.7 grams. You get dual SIM Nano-SIM option with an added eSIM compatibility.
Connectivity options include Bluetooth 5.0, WiFi (2.4G-5G), USB Type-C, and NFC. Navigation systems supported are A-GPS, GLONASS, GALILEO, and BDS. The Iron Ve is powered by a non-removable 6150mAh Li-Po battery with 10W fast charging. Additional features include wireless FM radio with RDS and recording capabilities. The phone is available in All Black and Some Orange colors.
Full Specifications
Details
| Launch This refers to the date when this device was officially introduced into the market. | Announced 2023, October / Released 2023, October |
| Brand / Model These are key identifiers that indicate the manufacturer or company that produces this smartphone, and the specific model of the phone. | Hammer / Iron Ve |
Network Technology
| 2G Bands 2G refers to the second generation of cellular technology and includes various frequency bands for basic voice and text communication. | 850 / 900 / 1800 / 1900 - SIM 1 and SIM 2 |
| 3G Bands 3G refers to the third generation of cellular technology, encompassing different frequency ranges for faster data speeds, mobile internet, and multimedia capabilities. | 800 / 850 / 900 / 1700(AWS) / 1900 / 2100 |
| 4G Bands 4G refers to the fourth generation of cellular technology, operating in specific frequency bands to provide significantly faster data speeds, supporting high-definition video streaming and advanced applications. | 1, 2, 3, 4, 5, 7, 8, 12, 17, 19, 20, 28, 34, 38, 39, 40, 41, 66 |
Body
| Ruggedity This indicates the device's durability and ability to withstand harsh conditions or impacts. It is a very popular term used with tough or rugged phones. IP68/IP69K are international ratings that measure a smartphone's resistance to dust and water. MIL-STD-810H is a military standard that sets criteria for the environmental and durability testing of electronic devices. It means this device has undergone various tests to demonstrate its resilience in challenging conditions, such as extreme temperatures, humidity, vibration, and shock. |
IP68 / IP69K / Mil-STD-810H - Water / dust resistant / drop-to-concrete resistance up to 1.5m |
| Dimensions / Weight: This refers to the physical size and weight of the device, measured in millimeter (mm) and grams (g) respectively. | 173 x 83 x 13.6 mm / 301.7 grams |
| SIM SIM stands for "Subscriber Identity Module." It is a small card, typically inserted into a slot in a mobile phone, that contains important information for connecting the device to a mobile network. SIM cards can come in various sizes, including standard SIM, micro SIM, nano SIM, or even electronic (eSIM), depending on the phone's design. | Dual SIM (eSIM, Nano-SIM, dual stand-by) |
Display
| Screen Display refers to the screen or visual interface of the device. It includes details such as screen size, resolution, and technology (e.g., LCD, OLED, AMOLED). | 6.52-inches / IPS LCD touch screen |
| Resolution Screen Resolution refers to the number of pixels that make up the display screen and is typically expressed as a combination of horizontal and vertical pixel counts (e.g., 1920 x 1080, 2560 x 1440, or 3840 x 2160). The screen resolution determines the level of detail and sharpness of the visual content displayed on the smartphone's screen. Higher resolutions generally result in crisper and more detailed images and text | 720 x 1600 pixels / 20:9 aspect ratio / 269 PPI |
| Features Camera features encompass various functionalities and capabilities that enhance the device's photography and videography experience. These features can include Optical Image Stabilization (OIS) Panorama, HDR, Ai Mode, Night Mode, Portrait Mode, etc. | Scratch resistant glass |
Platform
| OS This is the Operating System. It refers to the software platform that runs on the smartphone and manages the device's hardware and software resources. Common smartphone operating systems include Android (developed by Google), iOS (developed by Apple). | Google Android 13 |
| Chipset This refers to the integrated circuit that serves as the device's central processing unit (CPU). It plays a pivotal role in the smartphone's performance, speed, and energy efficiency. |
MMediatek Helio G36 (12 nm) - Octa-core (4x2.2 GHz Cortex-A53 & 4x1.7 GHz Cortex-A53) - PowerVR GE8320 |
| Memory This encompasses two components: storage capacity and RAM (Random Access Memory). Storage capacity, typically measured in gigabytes (GB) or terabytes (TB), dictates how much internal space is available for apps, files, and media storage. RAM, measured in gigabytes (GB), is temporary memory crucial for multitasking and app performance, with more RAM generally leading to smoother operation and faster task-switching capabilities. | 6GB RAM + 64GB ROM / SD-card support upto 512GB (dedicated slot) |
Camera
| Main The main camera, also known as the rear camera, is the primary camera on the back of the smartphone. It is typically used for capturing photos and videos in various scenarios and is often the more powerful and versatile camera on the device |
Dual cameras: - Main: 50MP, F/1.8 - Night Vision: 24MP, F/1.8 with dual infrared night vision lights |
| Selfie The selfie camera, also known as the front-facing camera, is the camera on the front of the smartphone, primarily used for capturing selfies and video calls | 8MP selfie camera (fixed focus), No LED flash |
| Features Camera features encompass various functionalities and capabilities that enhance the device's photography and videography experience. These features can include Optical Image Stabilization (OIS) Panorama, HDR, Ai Mode, Night Mode, Portrait Mode, etc. | 1080p@30fps video recording / LED Flash |
Communications
| Connectivity This encompasses the device's ability to connect and communicate with other devices and networks. It includes features such as cellular connectivity, Wi-Fi, Bluetooth, NFC (Near Field Communication), and USB connectivity options. | Bluetooth 5.0 A2DP, LE / WiFi 2.4G-5G / USB Type-C / NFC |
| Navigation Navigation refers to the device's ability to determine and display location information and provide directions to users. This functionality is usually powered by Global Positioning System (GPS) technology. | A-GPS, GLONASS, GALILEO, BDS |
| Sensors This refers to the various built-in sensors that enable the device to gather information from its environment and interactions. Common sensors found in rugged smartphones may include fingerprint sensor, light sensor, barometer sensor among others. | Fingerprint (side-mounted), accelerometer, proximity, compass, barometer, thermometer (skin temperature) |
Battery and Others
| Battery This section refers to the device's power source and its related specifications. This typically includes details such as the battery capacity, measured in milliampere-hours (mAh) or watt-hours (Wh), and it charging details. |
Li-Po 6150mAh, non-removable - 18W Fast battery charging - Reverse charging |
| Others This is a catch-all category that includes various additional features, specifications, or capabilities that don't fall under the major categories like display, camera, memory, or connectivity. |
Color: All Black / Some Orange Wireless FM radio, RDS, recording |
Disclaimer Note:
These specifications were entered manually, hence we CANNOT guarantee 100% accuracy. Also, that your device is listed on this website DOES NOT call for reckless usage! It is crucial to exercise due diligence, as we cannot be held responsible for any damage to your device due to overconfidence in it built quality.
